Os modelos de Conexões Tubulares Stub Ends e Caps – Tê de Reducação & Cruzeta fazem a ligação de diferentes canos e os fazem seguir para uma ou mais direções dependendo de seus modelos.
Conexões tubulares stub ends e caps também tem como função finalizar o caminho do sistema hidráulico, promovendo a vedação. Assim sendo, saiba mais a respeito desse produto a seguir. Veja também porque contar com a Feital para comprar essa e outras peças em aço.
Como funcionam as Conexões Tubulares Stub Ends e Caps – Tê de Redução & Cruzeta
Há alguns diferenciais importantes nas peças de tê de redução e de cruzeta para interligar canos com modelos stub ends e caps. Além da função estratégica no fim dos encanamentos para fecha-los, elas também contam com as seguintes características:
- Diferentes medidas e comprimentos para encaixe em vários tipos de encanamento;
- Modelos com libragens diversas para suportar elevados níveis de pressão;
- Traços técnicos que seguem parâmetros internacionais de qualidade;
- Versatilidade para se adaptar a diferentes canos e direciona-los adequadamente.
Além desses aspectos, cabe ressaltar também que utilizar esse tipo de conexões feitas de aço traz uma série de benefícios e vantagens extras.
A importância do aço inox como matéria-prima
O aço é um material que garante resistência e versatilidade para conexões tubulares stub ends e caps – tê de redução & cruzeta. Mas esta não é a única vantagem que ele oferece, uma vez que as peças que o utilizam como matéria-prima apresentam:
- Grande resistência a corrosão e ao desgaste natural do tempo;
- Estabilidade, uma vez que não são afetadas por mudanças mecânicas e de temperatura;
- Versatilidade, pois podem se encaixar em outros materiais com a mesma eficiência;
- Maior tempo de vida útil, o que lhe dá excelente relação custo-benefício.
É importante ter em mente que os modelos stub ends e caps funcionam como um fechamento para o tê de redução e a cruzeta. Dessa forma, conseguem encerrar o caminho do sistema hidráulico dando a ele a vedação adequada. Neste sentido, o uso do aço é ainda mais vantajoso.
Por outro lado, você precisa ter em mente que para aproveitar todos esses benefícios, contar com a empresa certa faz toda a diferença. Assim, veja a seguir porque comprar suas conexões na Feital.
Item # | Diâmetro Nominal – DxD1 | Centro A Face(Linha) – C (mm) | Centro A Face (Derivação) – M (mm) |
1/2″ | 1/2 | 25 | 25 |
1/2″x3/8″ | 1/2 x 3/8 | 25 | 25 |
1/2″x1/4″ | 1/2 x 1/4 | 25 | 25 |
3/4″ | 3/4 | 29 | 29 |
3/4″x1/2″ | 3/4 x 1/2 | 29 | 29 |
3/4″x3/8″ | 3/4 x 3/8 | 29 | 29 |
1″ | 1 | 38 | 38 |
1″x3/4″ | 1 x 3/4 | 38 | 38 |
1″x1/2″ | 1 x 1/2 | 38 | 38 |
1.1/4″ | 11/4 | 48 | 48 |
1.1/4″x1″ | 11/4 x 1 | 48 | 48 |
1.1/4″x3/4″ | 114 x 3/4 | 48 | 48 |
1.1/4″x1/2″ | 11/4 x 1/2 | 48 | 48 |
1.1/2″ | 11/02/2016 | 57 | 57 |
1.1/2″x1.1/4″ | 11/2 x 11/4 | 57 | 57 |
1.1/2″x1″ | 11/2 x 1 | 57 | 57 |
1.1/2″x3/4″ | 11/2 x 3/4 | 57 | 57 |
1.1/2″x1/2″ | 11/2 x 1/2 | 57 | 57 |
2″ | 2 | 64 | 64 |
2″x1.1/2″ | 2 x 11/2 | 64 | 60 |
2″x1.1/4″ | 2 x 11/4 | 64 | 57 |
2″x1″ | 2 x 1 | 64 | 51 |
2″x3/4″ | 2 x 3/4 | 64 | 44 |
2.1/2″ | 21/2 | 76 | 76 |
2.1/2″x2″ | 21/2 x 2 | 76 | 70 |
2.1/2″x1.1/2″ | 21/2 x 11/2 | 76 | 67 |
2.1/2″x1/14″ | 21/2 x 1/14 | 76 | 64 |
2.1/2″x 1″ | 21/2 x 1 | 76 | 57 |
3″ | 3 | 86 | 86 |
3″x2.1/2″ | 3 x 21/2 | 86 | 83 |
3″x2″ | 3 x 2 | 86 | 76 |
3″x1.1/2″ | 3 x 11/2 | 86 | 73 |
3″x1.1/4″ | 3 x 11/4 | 86 | 70 |
3.1/2″ | 31/2 | 95 | 95 |
3.1/2″x3″ | 31/2 x 3 | 95 | 92 |
3.1/2″x2.1/2″ | 31/2 x 21/2 | 95 | 89 |
3.1/2″x2″ | 31/2 x 2 | 95 | 83 |
3.1/2″x1.1/2″ | 31/2 x 11/2 | 95 | 79 |
4″ | 4 | 105 | 105 |
4″x3.1/2″ | 4 x 31/2 | 105 | 102 |
4″x3″ | 4 x 3 | 105 | 98 |
4″x2.1/2″ | 4 x 21/2 | 105 | 95 |
4″x2″ | 4 x 2 | 105 | 89 |
4″x1.1/2″ | 4 x 11/2 | 105 | 86 |
5″ | 5 | 124 | 124 |
5″x4″ | 5 x 4 | 124 | 117 |
5″x3.1/2″ | 5 x 31/2 | 124 | 114 |
5″x3″ | 5 x 3 | 124 | 111 |
5″x2.1/2″ | 5 x 21/2 | 124 | 108 |
5″x2″ | 5 x 2 | 124 | 105 |
6″ | 6 | 143 | 143 |
6″x5″ | 6 x 5 | 143 | 137 |
6″x4″ | 6 x 4 | 143 | 130 |
6″x3.1/2″ | 6 x 31/2 | 143 | 127 |
6″x3″ | 6 x 3 | 143 | 124 |
6″x2.1/2″ | 6 x 21/2 | 143 | 121 |
8″ | 8 | 178 | 178 |
8″x6″ | 8 x 6 | 178 | 168 |
8″x5″ | 8 x 5 | 178 | 162 |
8″x4″ | 8 x 4 | 178 | 156 |
8″x3.1/2″ | 8 x 31/2 | 178 | 152 |
10″ | 10 | 216 | 216 |
10″x8″ | 10 x 8 | 216 | 203 |
10″x6″ | 10 x 6 | 216 | 194 |
10″x5″ | 10 x 5 | 216 | 191 |
10″x4″ | 10 x 4 | 216 | 184 |
12″ | 12 | 254 | 254 |
12″x10″ | 12 x 10 | 254 | 241 |
12″x8″ | 12 x 8 | 254 | 229 |
12″x6″ | 12 x 6 | 254 | 219 |
12″x5″ | 12 x 5 | 254 | 216 |
14″ | 14 | 279 | 279 |
14″x12″ | 14 x 12 | 279 | 270 |
14″x10″ | 14 x 10 | 279 | 257 |
14″x8″ | 14 x 8 | 279 | 248 |
14″x6″ | 14 x 6 | 279 | 238 |
16″ | 16 | 305 | 305 |
16″x14″ | 16 x 14 | 305 | 305 |
16″x12″ | 16 x 12 | 305 | 295 |
16″x10″ | 16 x 10 | 305 | 283 |
16″x8″ | 16 x 8 | 305 | 273 |
16″x6″ | 16 x 6 | 305 | 264 |
18″ | 18 | 343 | 381 |
18″x16″ | 18 x 16 | 343 | 330 |
18″x14″ | 18 x 14 | 343 | 330 |
18″x12″ | 18 x 12 | 343 | 321 |
18″x10″ | 18 x 10 | 343 | 308 |
18″x8″ | 18 x 8 | 343 | 298 |
20″ | 20 | 381 | 381 |
20″x18″ | 20 x 18 | 381 | 368 |
20″x16″ | 20 x 16 | 381 | 356 |
20″x14″ | 20 x 14 | 381 | 356 |
20″x12″ | 20 x 12 | 381 | 346 |
20″x10″ | 20 x 10 | 381 | 333 |
20″x8″ | 20 x 8 | 381 | 324 |
22″ | 22 | 419 | 419 |
22″x20″ | 22 x 20 | 419 | 406 |
22″x18″ | 22 x 18 | 419 | 394 |
22″x16″ | 22 x 16 | 419 | 381 |
22″x14″ | 22 x 14 | 419 | 381 |
22″x12″ | 22 x 12 | 419 | 371 |
22″x10″ | 22 x 10 | 419 | 359 |
24″ | 24 | 432 | 432 |
24″x22″ | 24 x 22 | 432 | 432 |
24″x20″ | 24 x 20 | 432 | 432 |
24″x18″ | 24 x 18 | 432 | 419 |
24″x16″ | 24 x 16 | 432 | 406 |
24″x14″ | 24 x 14 | 432 | 406 |
24″x12″ | 24 x 12 | 432 | 397 |
24″x10″ | 24 x 10 | 432 | 384 |
26″ | 26 | 495 | 495 |
26″x24″ | 26 x 24 | 495 | 483 |
26″x22″ | 26 x 22 | 495 | 470 |
26″x20″ | 26 x 20 | 495 | 457 |
26″x18″ | 26 x 18 | 495 | 444 |
26″x16″ | 26 x 16 | 495 | 432 |
26″x14″ | 26 x 14 | 495 | 432 |
26″x12″ | 26 x 12 | 495 | 422 |
28″ | 28 | 521 | 521 |
28″x26″ | 28 x 26 | 521 | 521 |
28″x24″ | 28 x 24 | 521 | 508 |
28″x22″ | 28 x 22 | 521 | 495 |
28″x20″ | 28 x 20 | 521 | 483 |
28″x18″ | 28 x 18 | 521 | 470 |
28″x16″ | 28 x 16 | 521 | 457 |
28″x14″ | 28 x 14 | 521 | 457 |
28″x12″ | 28 x 12 | 521 | 448 |
30″ | 30 | 559 | 559 |
30″x28″ | 30 x 28 | 559 | 546 |
30″x26″ | 30 x 26 | 559 | 546 |
30″x24″ | 30 x 24 | 559 | 533 |
30″x22″ | 30 x 22 | 559 | 521 |
30″x20″ | 30 x 20 | 559 | 508 |
30″x 18″ | 30 x 18 | 559 | 495 |
30″x16″ | 30 x 16 | 559 | 483 |
30″x14″ | 30 x 14 | 559 | 483 |
30″x12″ | 30 x 12 | 559 | 473 |
30″x10″ | 30 x 10 | 559 | 460 |
32″ | 32 | 597 | 597 |
32″x30″ | 32 x 30 | 597 | 584 |
32″x28″ | 32 x 28 | 597 | 572 |
32″x26″ | 32 x 26 | 597 | 572 |
32″x24″ | 32 x 24 | 597 | 559 |
32″x22″ | 32 x 22 | 597 | 546 |
32″x20″ | 32 x 20 | 597 | 533 |
32″x18″ | 32 x 18 | 597 | 521 |
32″x16″ | 32 x 16 | 597 | 508 |
32″x14″ | 32 x 14 | 597 | 508 |
34″ | 34 | 635 | 635 |
34″x32″ | 34 x 32 | 635 | 622 |
34″x30″ | 34 x 30 | 635 | 610 |
34″x28″ | 34 x 28 | 635 | 597 |
34″x26″ | 34 x 26 | 635 | 597 |
34″x24″ | 34 x 24 | 635 | 584 |
34″x22″ | 34 x 22 | 635 | 572 |
34″x20″ | 34 x 20 | 635 | 559 |
34″x18″ | 34 x 18 | 635 | 546 |
34″x16″ | 34 x 16 | 635 | 533 |
36″ | 36 | 673 | 673 |
36″x34″ | 36 x 34 | 673 | 660 |
36″x32″ | 36 x 32 | 673 | 648 |
36″x30″ | 36 x 30 | 673 | 635 |
36″x26″ | 36 x 26 | 673 | 622 |
36″x28″ | 36 x 28 | 673 | 622 |
36″x24″ | 36 x 24 | 673 | 610 |
36″x22″ | 36 x 22 | 673 | 597 |
36″x20″ | 36 x 20 | 673 | 584 |
36″x18″ | 36 x 18 | 673 | 572 |
36″x16″ | 36 x 16 | 673 | 559 |
38″ | 38 | 711 | 711 |
38″x36″ | 38 x 36 | 711 | 711 |
38″x34″ | 38 x 34 | 711 | 698 |
38″x32″ | 38 x 32 | 711 | 686 |
38″x30″ | 38 x 30 | 711 | 673 |
38″x28″ | 38 x 28 | 711 | 648 |
38″x26″ | 38 x 26 | 7111 | 648 |
38″x24″ | 38 x 24 | 711 | 635 |
38″x22″ | 38 x 22 | 711 | 622 |
38″x20″ | 38 x 20 | 711 | 610 |
38″x18″ | 38 x 18 | 7111 | 597 |
40″ | 40 | 749 | 749 |
40″x38″ | 40 x 38 | 749 | 749 |
40″x36″ | 40 x 36 | 749 | 737 |
40″x34″ | 40 x 34 | 749 | 724 |
40″x32″ | 40 x 32 | 749 | 711 |
40″x30″ | 40 x 30 | 749 | 698 |
40″x28″ | 40 x 28 | 749 | 673 |
40″x26″ | 40 x 26 | 749 | 673 |
40″x24″ | 40 x 24 | 749 | 660 |
40″x22″ | 40 x 22 | 749 | 648 |
40″x20″ | 40 x 20 | 749 | 635 |
40″x18″ | 40 x 18 | 749 | 622 |
42″ | 42 | 762 | 711 |
42″x40″ | 42 x 40 | 762 | 711 |
42″x38″ | 42 x 38 | 762 | 711 |
42″x36″ | 42 x 36 | 762 | 711 |
42″x34″ | 42 x 34 | 762 | 711 |
42″x32″ | 42 x 32 | 762 | 711 |
42″x30″ | 42 x 30 | 762 | 711 |
42″x28″ | 42 x 28 | 762 | 698 |
42″x26″ | 42 x 26 | 762 | 698 |
42″x24″ | 42 x 24 | 762 | 660 |
42″x22″ | 42 x 22 | 762 | 660 |
42″x20″ | 42 x 20 | 762 | 660 |
42″x18″ | 42 x 18 | 762 | 648 |
42″x16″ | 42 x 16 | 762 | 635 |
44″ | 44 | 813 | N/A |
44″x42″ | 44 x 42 | 813 | 762 |
44″x40″ | 44 x 40 | 813 | 749 |
44″x38″ | 44 x 38 | 813 | 737 |
44″x36″ | 44 x 36 | 813 | 724 |
44″x34″ | 44 x 34 | 813 | 724 |
44″x32″ | 44 x 32 | 813 | 711 |
44″x30″ | 44 x 30 | 813 | 711 |
44″x28″ | 44 x 28 | 813 | 698 |
44″x26″ | 44 x 26 | 813 | 698 |
44″x24″ | 44 x 24 | 813 | 686 |
44″x20″ | 44 x 20 | 813 | 686 |
46″ | 46 | 851 | 800 |
46″x44″ | 46 x 44 | 851 | 800 |
46″x42″ | 46 x 42 | 851 | 787 |
46″x40″ | 46 x 40 | 851 | 775 |
46″x38″ | 46 x 38 | 851 | 762 |
46″x36″ | 46 x 36 | 851 | 762 |
46″x34″ | 46 x 34 | 851 | 749 |
46″x32″ | 46 x 32 | 851 | 749 |
46″x30″ | 46 x 30 | 851 | 737 |
46″x28″ | 46 x 28 | 851 | 737 |
46″x26″ | 46 x 26 | 851 | 737 |
46″x24″ | 46 x 24 | 851 | 724 |
46″x22″ | 46 x 22 | 851 | 724 |
48″ | 48 | 889 | 838 |
48″x46″ | 48 x 46 | 889 | 838 |
48″x44″ | 48 x 44 | 889 | 838 |
48″x42″ | 48 x 42 | 889 | 813 |
48″x40″ | 48 x 40 | 889 | 813 |
48″x38″ | 48 x 38 | 889 | 813 |
48″x36″ | 48 x 36 | 889 | 787 |
48″x34″ | 48 x 34 | 889 | 787 |
48″x32″ | 48 x 32 | 889 | 787 |
48″x30″ | 48 x 30 | 889 | 762 |
48″x28″ | 48 x 28 | 889 | 762 |
48″x26″ | 48 x 26 | 889 | 762 |
48″x24″ | 48 x 24 | 889 | 737 |
48″x22″ | 48 x 22 | 889 | 737 |
